REVIC Optics
REVIC Optics PMR428 4.5-28x56 MOA RT1 Scope E2600
This item may be regulated for export by the U.S. Department of State or the US Department of Commerce. Please see our Export Policy
Description
The REVIC Optics PMR428 4.5-28x56 is the next step in the evolution of riflescopes with features like Bluetooth compatibility, heads up display (HUD), and an on-board ballistics computer. REVIC Optics, a subsidiary of Gunwerks spent five years developing the PMR428 ensuring that it wouldn’t just enter the market as one of the most advanced riflescopes but as one of the most reliable too.
The heart and soul of the PMR428 is the ballistics computer with data coming from both the shooter and the scope. This highly intuitive system allows for nearly effortless long range shots, just a matter of dialing in the elevation turret to the target range. The scope itself features a suite of sensors including compass, incline, cant, pressure, temperature, and absolute positional rotary encoder. The integrated ballistics computer calculates: vertical drop, directional wind, spin drift, coriolis, and aerodynamic jump.
The user is responsible for defining the settings and providing some input via the ballistic app.
User Defined Settings
- Timeout in 5min Increments
- Illuminated Reticle Color
- Illuminated Reticle Intensity
- Display Intensity
- Sensor Temperature Override
- Latitude
- Nominal Wind Speed
- Wind Vector
- Coriolis On/Off
- Zero Range & Offset
- Muzzle Velocity & Ballistic Coefficient
Ballistic App Inputs
- Sight Height
- Mount Angle
- Barrel Twist and Direction
- Muzzle Velocity
- Ballistic Coefficient (G1, G7, CDM)
- Bullet Weight
- Bullet Length
- Caliber
- Zero Range
Specifications
SKU
E2600-REVIC
UPC
855666005063
MPN
AY-E2600
Exit Pupil
8.4 - 2mm
Eye Relief
85mm–82mm
Field of View
4.53°–.83°
Illuminated Reticle
Yes, AAA Lithium Battery
Light Transmission
84.4% @ 550nm
Magnification Range
4.5–28
Parallax Adjustment
50 yds–∞
Reticle Position
First Focal Plane
Elevation Turret Details
30 MOA per revolution
85 MOA Total Elevation
Scope Finish
Dark Matte Gray
Scope Length
Mechanical Length: 14"
Mounting Length: 6.3"
Scope Objective Diameter
56mm
Reticle Details
Revic PMR428 RT1 Reticle with digital display
Scope Tube Size / Mount
34mm
Turret Adjustment (Click Value)
.25 MOA per click
Scope Weight
47 oz.
Windage Turret Details
50 MOA Total Windage
Item Condition
New
Product Type
Riflescopes
Scope Turret Rotation
Counter Clockwise (CCW)
