US Optics B-17 3.2-17x50 Illum GAP Scope
LIMITED STOCK

US Optics

US Optics B-17 3.2-17x50 Illum .1mrad GAP Scope

SKU:B-17-GAP-USO
(0)

Additional Payment Options

Government Export Restriction

This item may be regulated for export by the U.S. Department of State or the US Department of Commerce. Please see our Export Policy

Description

Modern rifle scopes must meet the demands placed upon them in an operational sense, as well as satisfy consumers. It's not always easy to do both, but U.S. Optics has come up with a winner in their new "B" Series, which includes the B-10, B-17, and B-25 scopes.

The B-10 is a medium-range scope, meant to engage targets out to a range of ~1,000 - 1,200 yards. The B-17 is a medium-long range scope, meant to engage targets out to a range of ~1,500 - 1,700 yards. Finally, the B-25 is a long-range scope, meant to engage targets out to a range of ~2,500-yards (and potentially further) in the hands of a capable marksman.

Though the general rule of thumb is 1x magnification power for every 100-yds (approximately) range between the shooter and the target, there are certainly scopes with low-grade lens materials that can make successfully engaging a target at moderate- to long-distance a real challenge. Not so with the B Series. U.S. Optics utilizes premium lenses and materials in the construction of these scopes, sealing them against the elements.

A series with premium features and numerous reticle options, U.S. Optics' B-series scopes are destined to find their way on to precision rifles owned by the most discerning operators and competitors.

While the B-17 has the the popular 3.2-17x magnification, which is what many of today’s professionals are looking for, it has many other great features.

Features:

  • Locking elevation and windage knobs
  • Zero-stop
  • Revolution counter
  • Tool-less elevation zero
  • Single-button illumination control (integrated into the parallax adjustment knob)
  • 2 mm Exit Pupil Diameter
  • +2 to -3 Diopter
  • 2.3” / 58.63 mm Objective Lens Housing Diameter
  • 1.40” / 35 mm Ocular Lens Diameter
  • Lithium Coin battery (CR2032); runtime up to 8,000 Hours

The B-17 optics also have all the same durability, reliability, and performance that US Optics is known for. Additionally, this Anti-Reflective Device fits B-17 scopes and will block stray light rays from entering the objective lens, reducing glare in the process.

Specifications

SKU

B-17-GAP-USO

UPC

811069020737

MPN

B-17 GAP

Eye Relief

3.5" / 8.9cm

Field of View

Field of View @3.2x: 25.25' @ 100 yrds
Field of View @17x: 8.08' @100 yrds

Illuminated Reticle

Single-button illumination control (integrated into the parallax adjustment knob)
Color: Red

Magnification Range

3.2-17x

Parallax Adjustment

Side Focus Parallax 50yds->∞

Reticle Position

First Focal Plane

Scope Finish

Aluminum, 6061-T6 Type III hard anodized, matte black

Scope Length

15.02" / 381.50 mm

Scope Objective Diameter

1.96" / 50mm

Reticle Details

GAP Reticle

Scope Tube Size / Mount

1.33" / 34mm

Turret Adjustment (Click Value)

.1 MRAD
Total Elevation: 35 MRAD
Total Windage Range: 5 MRAD L / 5 MRAD R (once limiter is set)

Scope Weight

31.3oz / 0.881kg

Item Condition

New

Product Type

Riflescopes
